54000L GALVANISED STEEL WATER TANK

Product Description

54,000L GALVANISED STEEL WATER TANK

This 54,000 Litres Galvanised Steel Water Tank is a corrugated Galvanized steel water tank designed specifically to hold large quantities of water. The steel is approved to BS2989:1982 and is galvanized with lead free zinc to 275g/m² to EN10142. There is a minimum safety margin of 40% - this means that the structural strength of the tank is capable of holding a minimum of 40% more than the tanks actual volume. (It is not capable of holding more than the stated volume). The tanks are extremely strong and look aesthetically very pleasing.

Advantages:

Very Strong
Easy to install
Key design is flexibility of footprint and capacity - can be fitted into an existing plant/ civil layout
Photographic instruction manual provided
Cost effective solution to storing large quantities of water
Many sizes available - from 1.5m³ to 2000m³ and can also be supplied as linked tanks in a modular systems
Just two people can assemble
Portable, simple to move and reassemble
Effective - supplied in kit form for minimized transportation costs
Covers to suit any application: galvanised steel (with two hatches) or anti algae woven polypropylene
Minimum in-built 20% safety margin (40% for the TK range)
10 Year Warranty on panels and liners

Applications:

Storage of drinking water for emergency humanitarian aid
Rainwater harvesting for the recycling of water
Irrigation water for horticulture, nurseries and garden centres
Irrigation water for sports playing surfaces
Tanks for aquaculture
Dust suppression
Attenuation Tanks
Storage of water for dust suppression systems
Grey water storage

Included EPDM Liner:

Greenseal EPDM Irrigation Tank Lining Material 0.75mm - 1.00mm is a flexible robust material with excellent cut through, abrasion and UV resistance. EPDM offers a strong and more cost-efficient option than Butyl.

Colour: Matt Black
Abrasion Resistance: Excellent
Chemical Resistance: Good
Cut Through Resistance: Excellent
Flexibility: Very Flexible
Temperature Resistance: Very Good
UV Resistance: Excellent
Repair with Glue & patch

Other Options (please contact us for further information)

Various outlet options
Various inlet valve options
Access Ladder and Handrail Kit
Pipe enclosures
Platforms
Cast iron flanged gate valves

Tanks comes with all steel panels, nuts, bolts and washers, anchor kit, top and bottom tank capping, wire, strainer and EPDM liner as standard

Please request a quotation for specific Fire Water Tank in this size.

Fire and Rescue Service Support Tanks (FRST)

These tank systems provide additional water storage capacity available as quick release hydrant outlet directly from the tank or locally positioned hydrants on the site.

The capacity required is defined by Fire Officers Site Risk Assessment and relates to the duration and flow rate required to support hydrant servicing fire engine or hose reels on site.

Water from the tank is drawn by suction pumps either on board the appliance (to replenish inbuilt tank on the tender) or on site.

The tank incorporates a vortex inhibitor system with maximum flow on standard 4” 110 mm hydrant outlets of 50.0 LPS - Litres / Sec (Higher Flow Rates by special design)

Site Certification and Licensing

The FRST tank provision assists with overall specification within the FRS Risk Assessment and allows Fire Certification by FO and Operational Licenses for the site by Local Authority and Environment Agency Site

Basic Tank Specification for FRST

Basic Galvanised Steel Tank and Roof / Cover – 1.0 mm EPDM Liner – 4” DN100 Hydrant outlet- Vortex Inhibitor. Cast Iron Gate Valve. Liquid Level Indicator.
Configured for site water fill requirements.
Optional Powder Coating Finish
Tank supplied with 10 year Warranty and Certificate of Conformity

Commonly supplied in 50,000 to 500,000 litres sizes.

Please note image of tank is for illustration purposes only

Delivery 3-4 weeks

Product Specification

Product Code: EV
Made To Order: Made To Order
Non-returnable: Non-returnable
Potable: No
Shape: Cylindrical
Shipping: Customer Off Loading, Free Delivery
Volume: 54000ltr
Dimensions: H:2.29mm
Diameter: 5.49mm
