EBARA IDROGO AUTO PUMP

EBARA IDROGO AUTO PUMP

The IDROGO M 40/08 is a 5" submersible centrifugal multistage pump made of stainless steel AISI 304.

APPLICATIONS

• Moving clear water from wells & cisterns.
• Pressure boosting domestic plants
• Small-sale irrigation
• Rainwater Harvesting
• Washing vehicles
• General pressure increases


TECHNICAL DETAILS

• Equipped with twin mechanical seal with interposed oil chamber
• Supplied with 20 m of H07RN-F power supply cable (5m for IDROGO 40/06 M model)
• Single phase version with float on request (version "A")
• Available in the 230V ±10% 50Hz three phase version
• Installation: in horizontal and vertical position
• Idrogo M40/08A


PUMP TECHNICAL DATA

• Maximum working pressure: 10 bar
• Maximum temperature of the liquid: 40°C
• Maximum immersion for pumps with 20m cable (version with floatswitch): 10 m
• Maximum immersion for pumps with 20m cable: 17 m
• Maximum immersion for pumps with 5m cable: 2 m
• Maximum solid size passage: 2,5 mm
• G1¼ discharge connection

MOTOR TECHNICAL DATA

• 2 poles self-ventilated asynchronous motor cooled via the moving liquid
• Class of insulation F
• IP68 Protection degree
• 230V ±10%, 50Hz single-phase voltage
• 400 ±10%, 50Hz three-phase voltage
• Permanent capacitor inserted and thermo-amperometric protection with automatic reset incorporated for the single phase motor
• Protection under user's responsibility for the three phase version

MATERIALS

• External casing, motor cover, casing cover, filter and closing ring in AISI 304
• Impeller, diffuser and spacer in PPE+PS reinforced with fibreglass
• Shaft in AISI 431
• Upper mechanical seal (motor side) in Carbon/Ceramic/NBR and lower (pump side) in SiC/Carbon/NBR

• Product Code: KSP
• Potable: No
• Shipping: Free Delivery

tanks.ie undertakes to attempt to fulfill all orders within a maximum of 7 working days of order acceptance, unless advised otherwise. In the event that any order is delayed, tanks.ie will not be responsible for any consequential loss or damage that this delay may cause.

Smaller items (including most accessories and consumables) will normally be despatched by courier.
Larger items (including all storage tanks) will normally be delivered by carrier.

Kingspan Tanks - Tail-lift deliveries are available for most tanks up to 2,000 Litre capacities for kerbside delivery.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Klargester Tanks  - All tanks are delivered on 45ft Flat-bed Articulated Trailers, so off-loading equipment on site is necessary.
HIAB off-loading is available at extra cost, if requested.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Harlequin Tanks  - Tail-lift deliveries are available for most tanks up to 2,500 Litre capacities for kerbside delivery subject to availability.
It is the responsibility of the customer to inform us, if off-loading equipment is required.

Please note that for all items delivered by carrier, normally a truck + 40ft trailer, it is the customer's responsibility to ensure adequate vehicular access and to provide suitable offloading equipment, where required. Please notify us, if this might pose a problem and we will endeavour to facilitate your request.

ORDER CANCELLATION

In accordance with Irish and European Union consumer laws, you have seven days after receipt of order to cancel the order in its entirety or any part thereof, providing the goods are in a re-saleable condition. Should you wish to cancel any order, you must first contact sales@tanks.ie for a ‘Returns Authorisation Number’.

Please call 051 351325 or e-mail sales@tanks.ie


After the Returns Authorisation Number has been issued, we will make arrangements with you for the goods to be returned. If you wish tanks.ie to arrange the collection of the goods, please note that a carriage and administration charge will apply, which will not exceed 35% of the gross value of the goods.

Upon return of the cancelled goods to tanks.ie and verification that they are in a re-saleable condition, we will refund the value of the goods, less any collection and administration charges, within 28 days.

DEFECTIVE PRODUCTS

If you believe that products you have purchased from tanks.ie are defective, please report this immediately to tanks.ie by e-mail sales@tanks.ie or call 051 351325.

If they are within the manufacturer’s guarantee period, we will arrange with the manufacturer to replace or repair the goods at the manufacturer’s discretion and consistent with their guarantee.
Where it is necessary to inspect the goods on site and an inspection proves the fault is neither the fault of tanks.ie, nor the product manufacturer, an inspection charge will apply, which will be advised by the manufacturer prior to site inspection.

Please note that where guarantees are available in excess of those required by law, these are provided at the discretion of the product manufacturer and not tanks.ie. Additionally, tanks.ie will not be liable for any claims for consequential damage or loss.

Ebara Idrogo Brochure
