UV DISINFECTION UNIT 12GPM (45LPM)

UV DISINFECTION UNIT 8GPM (30LPM)

UV is a useful disinfection method of removing micro-organisms from water to make it safe to use. The UV Disinfection Units use UV light to destroy bacteria, viruses, spores and moulds and their ability to reproduce. Ultraviolet disinfection is extremely fast, it requires no chemicals or additives and cannot be overdosed. No chemical residuals are left in the treated water. The UV intensity (dose) is measured in mJ/cm2. For domestic situations UV systems should give at least 30 mJ/cm2 and for larger industrial systems 40 mJ/cm2. The dose required to inactivate bacteria depends on the bacteria. The higher the dose of UV the more of each bacteria are killed.

The UV disinfection unit eliminates the risk of overdoing using chemicals or leaving an unpleasant taste. UV sterilizers are low maintenance and are cheap to run. These systems are designed for low to medium flow rate applications. The lamps offer a full 1 year lifespan and inexpensive replacement costs.

All systems incorporate the latest high frequency lamp driver circuitry with lamp

• operating / failure warning lights
• 9000 hour life output UVC lamps
• 304 mirror finish stainless steel construction

Typical Applications:

• Drinking water from wells, springs and other untreated supplies
• Water filtration and treatment plants
• Fish farms, for the control of micro-organisms
• Algae control inonds and general aquatic use
• Re-circulating loops and high purity water systems

This UV disinfection unit requires 20" Filter Housing with 20" Water Filter 5 Micron cartridge to be installed ahead of the UV unit.

Specification:
