What makes this ALARM the right choice?
Kingspan - High Oil Outdoor Alarm
The Kingspan separator Oil alarm is powered by mains & is supplied with a control unit and a Grease Conductivity probe.
You can monitor up to 3 probe units and the outlet relay enables the status of each unit to be signalled to a remote location of your choosing. The alarm can be installed up to 300m from the control panel (Cabling will need to be purchased separately)
WHATS IN THE BOX:
- Control Panel (230v)
- Grease Probe with 5m fly lead
FEATURES AND BENEFITS:
- Receive warnings of Oil within the separator
- Reduces site waste-management costs and ongoing servicing costs
- Complies with EN858-1&2 and PPG3
- Can be fitted to separators from all manufacturers
SPECIFICATION:
- Mains Powered: 230AC
- IP65 ABS Enclosure: 180 x 180 x 60mm
- Output: Clean Contact Relay
- Display: Liquid Crystal
- Alarm: Audible (Local)
- Probe Range: 200 metres max. (Dependent on cable style)
- Atex approved: Baseefa 08ATEX0110/1
- Specific Marking of Explosion Protection: EX II (1) G [Ex ia Ga] IIC (-2°C ≤ Ta ≤ +50°C)
Compatible probe types:
- High Oil: Conductivity or specific gravity
- High Liquid: Optical or float switch
- Silt: Optical
Technical data
Full specifications
| Reference | |
| SKU | 0017020 |
| EDEL code | DELIVERY |
Irish regulations
Installation & requirements
OFTEC regulation
All domestic oil tank installations in Ireland must be carried out by an OFTEC-registered technician. The tank must conform to IS:293 and be sited in accordance with IS:820.
Site requirements
The tank must stand on a level, load-bearing concrete base minimum 100 mm thick, extending 300 mm beyond the tank footprint on all sides. Ground must be clear of vegetation.
Bunding requirements
Bunded tanks are required within 10 m of a watercourse or drain. Secondary containment must hold 110% of the inner tank capacity. Check local planning conditions before installation.
