EBARA MULTIGO PUMP M40/08

EBARA MULTIGO PUMP M40/08

This is a Multigo 40/08 Vertical multistage centrifugal electric pump (AISI 304)


APPLICATIONS

• Flooded areas
• Boosting of hydraulic plants
• Fountains
• Rainwater Harvesting
• Allotments & Gardens


TECHNICAL DETAILS

• Quiet & Reliable
• Moving water cools the motor
• Durability ensured by interposed oil chamber
• Equipped with 20 metres of H07 RN-F power supply cable



PUMP TECHNICAL DATA

• Maximum working pressure: 10 bar
• Maximum temperature of the liquid: 40°C
• Maximum suction depth: 6 m
• G1frac14; suction and discharge connection
• MEI > 0,4



MOTOR TECHNICAL DATA

• Asynchronous motor cooled via the moving liquid
• Class of insulation F
• IP68 Protection degree
• 230V ±10%, 50Hz single-phase voltage, 400 ±10%, 50Hz three- phase voltage
• Permanent capacitor inserted and thermo-amperometric protection
with automatic rearm incorporated for the single phase motor
• Protection under user's responsibility for the three phase version



MATERIALS

• Pump casing, seal housing disc, external casing and motor cover in AISI 304
• Impeller and diffuser in PPE+PS reinforced with fibreglass
• Shaft in AISI 416
• Mechanical seal in Carbon/Ceramic/NBR
